Description
SPEC
PISTON
| Bore (Φ) |
Pin Dia (Φ) |
Length (mm) |
Recess | Comp.Height (mm) |
PistonCrownVolume (cc) |
Weight (g) |
Pin weight (g) |
Total weight (g) |
|---|---|---|---|---|---|---|---|---|
| 87.0 | 22.0 | 60 | ○ | 29.5 | 23.0 | 317 | 112 | 429 |
| Top ring B×T(mm) | Second ring B×T(mm) | Oil ring B×T(mm) |
|---|---|---|
| 1.2×3.1 | 1.2×3.9 | 2.5×3.1 |
CRANKSHAFT
| Stroke (mm) |
Weight (kg) |
STD Stroke (mm) |
Material | Pin Dia. (Φ) |
journal Dia. (Φ) |
|---|---|---|---|---|---|
| 100.0 | 29.0 | 86.0 | SNCM49 | 52 | 62 |
CONNECTING ROD
| Conrod | Conrod Bolt | Conrod Bearing | Material | ||||
|---|---|---|---|---|---|---|---|
| Length (mm) |
L.Diam×Length (mm) |
S.Diam×Length (mm) |
Bolt Size | Height Under Neck (mm) |
Inner Circum (mm) |
Bearing Width (mm) |
|
| 139.0 | φ55×26.0 | φ23×26 | 3/8-24 | 40 | 52 | 19.0 | SNCM439 |
Compression Ration Specs
| Bore | φ87.0 | |
|---|---|---|
| Gasket Thickness (mm) |
1.5 | 9.0 |
| 1.8 | 8.8 | |
| 2.0 | 8.7 | |
| Gasket Bore | 87.5 | |
